Description

● DIN Rail Installation
● Advanced pre-setting one week before
● Latest technology COMS quartz Mico-controller
● Digital electronics general purpose time swich with daily and weekly programs
● Repeat programs with 8 ON/OFF settings.
●To-the-minute setting accuracy.
● LCD displays real time to Hour/Minute and ON/AUTO/OFF.

Technical Data

●Voltage limit: AC180V ~ 264V (50/60Hz)
●Hysteresis: ≤1s/d (at25℃)
●Number of circuits: 1c
●Load capacity: 16A 250VAC（ohmic load cos Ø=1）
●On/off operation: 8on & 8off
●Minimum interval: 1 minute
●Service life: Mechanically: 10⁷
                         Electrically: 10⁵
●Weight : Approx 150g
●Ambient temperature: -10～55℃
●Display : LCD
●storage temperature: -20~70℃
●Battery backup: 150h
●Power consumption: 5VA
